Victron Lynx Class-T Power In - Intelligent DC distribution for lithium batteries

The Victron Lynx Class-T Power In is the heart of your energy storage system. It centralises and secures the energy distribution of your lithium batteries, guaranteeing optimum protection and maximum efficiency for your photovoltaic, mobile or marine system.

Universal intelligence

Designed for 12V, 24V and 48V systems, Lynx Class-T Power In integrates perfectly with the other modules in the Lynx range. It enables intelligent, centralised management via Cerbo GX or the VictronConnect application, providing total control of your energy and the state of your batteries.

Safety and reliability

Each installation is secure thanks to its positive and negative connection bars, as well as integrated earthing. Two slots for class T fuses (225A to 400A, sold separately) provide reliable protection against overcurrents and short circuits.

Scalable and modular

Lynx Class-T Power In is designed to adapt to your growing energy needs. It allows you to add several Lynx Class-T modules to manage several battery strings simultaneously, guaranteeing a durable and scalable installation.

Key benefits for self-consumption

• Optimisation of the energy from your photovoltaic panels.
• Reliable protection for your lithium batteries and your installation.
• Centralised, intelligent management via Cerbo GX and VictronConnect.
• Clean, scalable installation for residential, marine and mobile projects.

Detailed technical specifications

• Voltage range: 9 - 60 V DC
• Current rating: up to 1000 A continuous
• Compatible fuses: 225A, 250A, 350A, 400A (class T)
• Dimensions: 170 x 280 x 97 mm
• Weight: 2.1 kg
• Compatibility: Lynx Smart BMS, Lynx Distributor, Lynx Shunt VE.Can
• Full integration with Victron Energy systems for optimal monitoring and control

Safety advice & best practice

• Use suitable Class T fuses, purchased separately.
• Ensure tight, corrosion-free connections.
• Protect exposed cables and bars.
• Check that the installation complies with local electrical and fire safety regulations.
• Consider ventilation or heat dissipation if necessary depending on configuration.

Comparison of Lynx solutions: Power In, Distributor and Class-T

• Lynx Power In: this is the entry-level version. It's simply a busbar (positive and negative) for connecting up to four batteries or inverters. As it has no built-in fuses, protection must be installed upstream. This is the simplest and most economical option.
• Lynx Distributor: an evolution of the Power In. It can also connect up to four devices, but with integrated protection. Each connection has a slot for a MEGA fuse. Its main advantage is monitoring: it detects the state of each fuse and indicates whether it is blown, either via an LED or by transmitting the information to a Cerbo GX.
• Lynx Class-T Power In: a specific version of the Power In, adapted to systems fitted with modern lithium batteries capable of delivering very high short-circuit currents. It uses Class-T fuses, which are faster and have a much higher interrupting capacity than MEGA fuses. This makes it a safer solution for high-power installations based on lithium batteries.

Conclusion

The Lynx Class-T Power In is the central element of any modern energy storage installation. Reliable, scalable and perfectly adapted to photovoltaic systems, it ensures secure and optimised energy distribution, enabling users to make the most of their solar self-consumption and their lithium batteries.

FAQ - Victron Lynx Class-T Power In

1. What is the Victron Lynx Class-T Power In used for?
It is a DC distribution module designed to connect and protect up to two lithium battery strings using Class-T fuses.

2. Is this module compatible with all types of batteries?
Yes, it works with 12 V, 24 V and 48 V systems, and can be used with lithium, AGM, gel or lead, as long as the voltage and current are within specification.

3. Which fuses should I use?
The Lynx Class-T Power In is compatible with Class T fuses from 225 A to 400 A (to be purchased separately). The choice depends on the maximum current of your installation.

4. Can I monitor my batteries with this module?
On its own, no. But it integrates perfectly with other Victron equipment such as the Lynx Smart BMS or the Cerbo GX, which allow monitoring and control via the VictronConnect application.

5. Is this module easy to install?
Yes, it has integrated connections and clear busbars. For maximum safety, we recommend that you follow the Victron manual or leave the installation to a professional.
