Multisolar 15kW grid-injection-storage hybrid inverter

€4,117.36
Tax included
Multisolar-15
0712971128019

Multisolar 15kW Inverter: Optimize Your Solar Energy Production

The Multisolar 15kW is a hybrid three-phase inverter designed to maximize your solar self-consumption. Connected to the grid, it allows you to store excess energy in batteries and feed it back into the grid if necessary. Enjoy clean and cost-effective energy while contributing to the energy transition.

Why choose the Multisolar 15kW inverter?

  • Optimized Self-Consumption: Use your own solar energy and significantly reduce your electricity bills.
  • Maximum Flexibility: Adapt your system to your needs with multiple operating modes.
  • Optimal Performance: The 2 independent MPPT trackers ensure maximum energy yield.
  • Simplified Installation: Easy installation due to its compact design and intuitive LCD screen.
  • Remote Monitoring: Control your system remotely with SolarPower software.

Key Benefits:

  • Reduction in Electricity Bills: Benefit from free solar energy.
  • Environmental Respect: Reduce your carbon footprint.
  • Reliability and Durability: Enjoy high-quality equipment designed to last.

Multisolar 15kW: Invest in the Future of Energy.

This product is no longer manufactured, but discover its successor: the Multisolar 15kW Hybrid Three-Phase Inverter, the ideal solution for grid injection, combining performance and reliability.

Sorry, there are no more items in stock.

Comments (0)

No customer reviews for the moment.

Multisolar 15kW: Optimise your solar energy production

Onduleur hybride 15kW injection réseau - stockage MultisolarMultiSolar: Store the bare minimum in your batteries and feed it back into the grid, provided the batteries are full.

Conversely, use the grid to make up for the shortfall in winter production, and top up the batteries when it rains.

Optimize your production to the maximum and never worry about a power cut again.

Connect up to 14850Wp to the PV input of the inverterb Hybrid

Store and use your solar-generated electricity at a later date.

graphique consommation multisolar 15 kw

Onduleur hybride 15kW injection réseau - stockage MultisolarDescription

High-performance three-phase MultiSolar inverter for hybrid power systems.

Connect solar panels, batteries and, optionally, a mains input to power your system.

Enjoy top performance thanks to two independent integrated mppt trackers, as well as user-friendliness thanks to its compact design and intuitive LCD display.

  • Pure sine wave output signal: 10kW
  • Max PV input power: 14850Wp
  • AC input: 3-phase
  • AC output: 3-phase
  • Microprocessor-controlled for greater stability
  • Multiple operations:
  • Grid-connected, off-grid and grid-connected with back-up power
  • Integrated mppt solair charger (two independent inputs)
  • Backlit LCD display for easy, interactive operation
  • Multiple means of communication
  • "Green" alternative to generators
  • User-adjustable battery charging current, up to 200A

Remote control and UPS configuration

Connect the UPS to your computer using the USB cable supplied.

SolarPower software enables control and monitoring of multiple devices via LAN, Internet or USB.

Alert notifications, pop-up screen, sms and email.

Software

SolarPower 1.20SP10

configuration paramettre multisolar 15kW

Features

Phase
phase in / 3 phase out
Max. PV power 22500 W
Output power 15000 W
Max. load power 15000 W
Grid-connected operation
Solar input (DC)
Nominal DC voltage / Max. DC voltage
720
DC / 900 VDC
Starting voltage / Min. working voltage 320 VDC / 350 VDC
MPP voltage range 400 VDC - 800 VDC
Number of MPP inputs / max. input current
: 37.65A ; B:18.

6

A
Consumer output (AC)
Rated output voltage 230 VAC (P-N)/400 VAC (P-P)
Output voltage range 184 - 264.5 VAC per phase
Rated output current 21.7 A per phase
Power factor >
0.99
Efficiency
Maximum conversion efficiency (DC/AC) 96.00%
European voltage efficiency 95,00%
Off-grid operation
AC input
AC starting voltage / automatic restart voltage 120 - 140 VAC per phase
180 VAC per phase
Input voltage range 170 - 280 VAC per phase
Max. AC input current. 40
A
Solar input (DC)
Max. DC voltage 900
VDC
MPP voltage range 350 VDC - 850 VDC
Number of MPP inputs/max. input current
: 37.65A; B:18.6A
Battery mode output (AC)
Nominal output voltage 230 VAC (P-N)/400 VAC (P-P)
Signal form Pure sinus
efficiency (DC/AC) 91,00%
Hybrid operation
Solar input (DC)
DC voltage nominal / DC voltage max. 720
VDC / 900 VDC
Starting voltage / Min. working voltage 320 VDC / 350 VDC
MPP voltage range 350 VDC - 850 VDC
Number of MPP inputs / max. input current
: 37.65A ; B:18.6A
Consumer output (AC)
Rated output voltage 230 VAC (P-N)/400 VAC (P-P)
MPP voltage range 184 - 264.5 VAC per phase
Rated output current 21,
A per phase
AC input
Starting voltage/Minimum working voltage 120 - 140 VAC per phase
180 VAC per phase
Input voltage range 170 - 280 VAC per phase
Max. AC input current 40
A
Battery mode output (AC)
Nominal output voltage 230 VAC (P-N)/400 VAC (P-P)
efficiency (DC/AC) 91.00%
Batteries and charger
Nominal DC voltage 48 VDC
Max. charging current
Default 60A,

5

A -300A (adjustable)
General specifications
Physical specifications
Dimensions P x W x H 219 x 650 x 820 mm
Weight 62 Kg
interface
Communication port RS-232 / USB and CAN Interface
Intelligent Slot SNMP,
Modbus and AS-400 cards available as options
Environment
- 90% RH (non-condensing)
Humidity
to 55°C
Working temperature
- 1000 m
Multisolar-15

Data sheet

Inverter power
15000VA
Phase
Triphasé
Number of MPPT
2 MPPT
Width
500 mm
Height
622 mm
Thickness
176 mm
Inverter type
Hybrid
Weight
62 kg

Specific References

UPC
712971128019
EAN13
0712971128019
